Klieverik GTC
The Klieverik GTC belt calenders are versatile machines, ideal for both roll-to-roll dye-sublimation transfer printing (from paper to textile) and for dye fixation of directly printed dispersed dyes or pigments. They cater to a wide range of users, from entry-level professionals to high-production environments.
Description
Product Info
- Low tension textile winding for stretch sensitive materials
- Textile tensioning device
- Universal unwind shaft for textile rolls for any core diameter
- Wind and unwinding shafts for transfer and protection paper, each with tensioning device
- Contact winder for textile
- Scraper blades to prevent paper or textile from wrapping around the drum and cleaning of the drum
- Air pressure operated paper tension setting
- Touchscreen
Professional Output
Engineered for precision, these calenders offer sharp edge clarity, high-speed processing, reduced material waste, and fewer reprints, ultimately enhancing profitability.Available Options
The GTC comes with options such as a low tension textile winding unit for stretch sensitive materials, Driven substrate expander, Edge cutting Unit, Compressor, Pneumatic winding shafts, Exhaust hood, Pressure laminating rollerApplications
The GTC is suitable for a variety of fabrics, including woven, stretch, knitted, and non-woven materials, making them particularly valuable for applications in signage, fashion, and home décor industries.Product Video
Technical Specifications
| Features | GTC 81/1850 | GTC 81/2300 | GTC 81/3400 |
| Working Width | 1650 mm | 2100 mm | 3200 mm |
| Speed | 0,1 - 2 m/min | 0,1 - 2 m/min | 0,1 - 2 m/min |
| Production sq.m./hour | 70 sq.m. | 90 sq.m. | 140 sq.m. |
| Temperature | 0 - 220C | 0 - 220C | 0 - 220C |
| Drum Diameter | 195mm | 195mm | 195mm |
| Dwell Time | 210 -10 sec | 210 -10 sec | 210 -10 sec |
| Total installed power | 10kVA | 13kVA | 19kVA |
